Large 90 Ltr. Tank Capacity
	3 Speed Motor
	Cools up to 2500* Sq. Ft. Area
	30 Inch Fan Blade
	Large Pad Area
	Fully functional knob control

TECHNICAL SPECIFICATION

PARAMETERS	VALUE
Motor Type	Single Phase, 3 Speed
RPM	950 RPM
Wattage / HP	490*W / 0.67* HP
Fan Type / Fan Noise	Axial Fan / 68* db
Air Flow / CFM	18000* CMH / 10500* CFM
Cooling Pad Size	1100x100x1150mm
Gross Weight	49 Kg
Product Dimension	1135x600x1535mm
Effective Cooling Area	2500* Sq. Ft.

3 Months Conditional Warranty

Starts from the date of INVOICE

Warranty is at Ex. factory all transportation & courier (To & Fro) charges to be born by CONSUMER

Warranty is covered for

(1) MOTOR
(2) PUMP
(3) KNOB SWITCH
(4) POWER CORD
(5) CASTOR WHEELS (FRONT & BACK)
(6) PLASTIC BODY &
(7) ALL PLASTIC PARTS
NO warranty on COOLING PAD
